Features
The Jit Homes floor guide (DJSD-7140A) is designed for frameless double sliding glass door applications within the D7100A Series.
Dual-channel tracking component is installed on the floor to maintain the parallel alignment of two bypassing glass panels.
Integrated internal gaskets keep the glass stabilized within the channels, preventing the panels from vibrating or swinging during movement.
Manufactured from stainless steel with a polished finish, it is built to perform reliably in the high-humidity conditions of wet-area shower environments.
The D7100A Series accommodates glass thicknesses from 5/16″ to 3/8″ (8–10 mm) and can also be custom-made to support 1/4″ (6 mm) and 1/2″ (12 mm) glass thicknesses.
The series supports a maximum door weight of 176.4 lb (80 kg), with a maximum door width of 73″ (1854 mm) and a maximum door height of 79″ (2000 mm).
Designed to work in conjunction with the other D7100A Series hardware components, it supports installation lengths of 60″ (1524 mm) and 73″ (1854 mm) to suit a range of standard shower enclosure configurations.
Finishes Available
Choose from a range of classic and contemporary finishes to match your space:
- Polished Stainless Steel
- Satin stainless steel
- Brushed Gold Stainless Steel
Looking for something different? Other finishes available on request.
